Friction Feed Paper Folding Machine (PGV FF 615)

Friction Feed Paper Folding Machine (PGV FF 615)

Friction Feed Paper Folding Machine (PGV FF 615) is equipped with a high speed friction feeder enabling it to handle a wide range of paper with ease and efficiency. We offer the Friction Feed Folding Machine at competitive prices to the valued clients.


Special Features

  • Basic four parallel folds' machine
  • Combination of six folding pockets and five deflectors
  • Maximum six folds are available
  • Single, double or triple folds
  • Different styles such as accordion fold,  fold, double parallel fold, uneven folds etc.
  • Suitable for non coating jobs
  • Feeds a single paper at a time
  • Setting of paper is easy to understand
  • Rotary scoring (creasing) attachment
  • Belt drive coupled with thick end plates ensures smooth and low noise working
  • Caliper setting and jogging mode available
  • Compatible with optional vertical stacker
  • Ergonomic design
  • User friendly operating panel
  • Emergency stop
  • Optional noise reduction hoods and/li>
  • Paper Jam Detection feature



Specifications :

Max. Format 375 x 600 mm Min. Format 70 x 110 mm Min. Folding 18 mm Output 19000 sheets per hour (A 4 / single fold) Roller Speed 150 m / min Paper Gsm 47 gsm to 130 gsm Power 220 V, 1 ph, 250 W With Maintenance free AC Drive
